Vatech A9 (PHT-30CSS)
Technical manual
VDH-TeM-098
184 / 214
COPYRIGHT© 2020 VATECH.
To check the saved Parameter value in MAIN MCU BOARD, send the
[SPM_PVER] command in the Terminal 1.9b program.
The Parameter values in this manual are random numbers only for
explanation. Thus do not refer to the Parameter Values written in this
manual since the actual Parameter Values for your system differ from
these values. Wrong inputs of the Parameter value may damage the
equipment.
<===== V-POP (MCU028) =====>
@@MAIN_Version:9.00.00
<=========================>
#############################################
#############################################
#############################################
## V-POP START ##############################
#############################################
#############################################
#############################################
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
R-axis initial position by exposure mode
0191=>(spm_HFST_xxxx)PANO HALF_COUNT
0226=>(spm_ACHF_xxxx)ARCT_HALF_COUNT
0226=>(spm_CPHF_xxxx)CEPH_HALF_COUNT
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
PANO, ARCT R axis starting position offset
00095=>(spm_POFS_xxxxx)ROTATOR_OFFSET_COUNT
00001=>(spm_COFS_xxxxx)ARCT_ROTATOR_OFFSET_COUNT
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
PANO sequence typesetting(not used)
0000=>(spm_PSTY_000x)PANO SEQUENCE MODE IS?
0: 200Hz(Normal PANO) type, 400Hz(Fast PANO /*child349Hz) (default)
1: 400Hz(Normal PANO) type, 400Hz(Fast PANO /*child349Hz )
2: 200Hz(Normal PANO) type, 300Hz(Fast PANO /*child300Hz)
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
CT/PANO Sensor initial position by exposure mode
0580=>(spm_PMCT_xxxx) PANO SENSOR REF (0580 = 5.80cm)
0438=>(spm_CMCT_xxxx)CT SENSOR REF (0431 = 4.31cm)
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
CEPH mode setting
0005=>(spm_CISC_000x)CEPH MODE IS?
0: Disable
1: Scan CEPH (cone beam ceph)
To Next Page
