Vatech A9 Technical Manual

Vatech A9 (PHT-30CSS)
Technical manual
VDH-TeM-098
185 / 214
COPYRIGHT© 2020 VATECH.
ALL RIGHTS RESERVED
2: Scan CEPH (fan beam ceph-No USE!!)
3: One-Shot CEPH (R-Troy, Large FOV)
4: One-Shot CEPH (TOK-Troy, Small FOV)
5: Scan CEPH (Table Control)
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
~~~ceph sensor start position offset~~~
1700=>(spm_UATT_xxxx)CEPH_TABLE_A_START_OFFSET_COUNT (0165 = 16.5cm).
0300=>(spm_UBTT_xxxx)CEPH_TABLE_B_START_OFFSET_COUNT (0165 = 16.5cm).
1700=>(spm_UCTT_xxxx)CEPH_TABLE_C_START_OFFSET_COUNT (0165 = 16.5cm).
0350=>(spm_UDTT_xxxx)CEPH_TABLE_D_START_OFFSET_COUNT (0165 = 16.5cm).
1700=>(spm_UETT_xxxx)CEPH_TABLE_E_START_OFFSET_COUNT (0165 = 16.5cm).
0350=>(spm_UFTT_xxxx)CEPH_TABLE_F_START_OFFSET_COUNT (0165 = 16.5cm).
1700=>(spm_UGTT_xxxx)CEPH_TABLE_G_START_OFFSET_COUNT (0165 = 16.5cm).
0350=>(spm_UHTT_xxxx)CEPH_TABLE_H_START_OFFSET_COUNT (0165 =
16.5cm).0313(HZ)=>(spm_CFRQ_xxxx)CEPH PULSE HZ SET
1790=>(spm_XRFA_xxxx)CEPH_REF_X1_START POSITION (1730 = 17.3cm)
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Collimator type
0002=>(spm_COTY_xxxx)COLLIMATOR TYPE SET (0: No collimator)(1: Using 4axis collimator)(2:
Using 1axis collimator)
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
10200=>(spm_COVS_xxxxx)1axis-COL_OFFSET_VAL(1xxxx=> "-val" (1 = 0.01016mm)
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
 1-axis collimator position by exposure mode
11395=>(spm_CBST_xxxxx)COL_PANO_CHILD_VAL (1axis collimator) (00001 = 1pulse)
912 is default by machanical data
03685=>(spm_CCST_xxxxx)COL_PANO_VAL (1axis collimator) (00001 = 1pulse)
3450 is default by machanical data
06660=>(spm_CFST_xxxxx)COL_CT_VAL (1axis collimator) (00001 = 1pulse)
6350 is default by machanical data
09150=>(spm_CGST_xxxxx)COL_CEPH_VAL (1axis collimator) (00001 = 1pulse)
8899 is default by machanical data
11969=>(spm_CDST_xxxxx)COL_FILTER_VAL (1axis collimator) (00001 = 1pulse)
11969 is default by machanical data
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Sensor and collimator drive ratio
122=>(SPM_PSCR) pano_sm_cm_ratio
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
R axis motor torque setting
0025 =>(SPM_RMRT_0001) R_M_RUN_TORQUE
0005 =>(SPM_RMST_0001) R_M_STOP_TORQUE
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
PANO,CT sensor mortor, Collimator motor, CEPH sensor motor torque setting - GMRT, GMST
disabled (3D camera)
2000 =>(SPM_LMRT_0001) LASER_M_RUN_TORQUE
0050 =>(SPM_LMST_0001) LASER_M_STOP_TORQUE
2500 =>(SPM_TSRT_0001) TEMPLE_M_RUN_TORQUE
