Vatech A9 Technical Manual

Vatech A9 (PHT-30CSS)
Technical manual
VDH-TeM-098
186 / 214
COPYRIGHT© 2020 VATECH.
ALL RIGHTS RESERVED
0200 =>(SPM_TSST_0001) TEMPLE_M_STOP_TORQUE
20000 =>(SPM_GMRT_0001) G_M_RUN_TORQUE
01000 =>(SPM_GMST_0001) G_M_STOP_TORQUE
20000 =>(SPM_HMRT_0001) H_M_RUN_TORQUE
01000 =>(SPM_HMST_0001) H_M_STOP_TORQUE
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
 Disabled (3D camera lighting)
00600 =>(SPM_CWFQ_0600) CWLED_PULSE_HZ
00050 =>(SPM_CWDT_0050) CWLED_PULSE_DT
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
 Door lock setting
0000=>(spm_DROP_000x)DOOR_TYPE
0: NO door switch Mode
1: Using door switch mode
 Tube tilting setting
0001=>(spm_TITY_000x)TILT_TYPE
0: NO tube tilting Mode (for only PANO Model)
1: Using tube tilting mode
 Auto Return setting
0001=>(spm_RTOP_000x)RETURN_TYPE
0: NO
Auto Return Mode
1: Using
Auto Return mode
 Exposure voice settings
0000=>(spm_EPOP_000x)EXPOSURE_TYPE
0: Normal Mode
1: Sound delay mode
 Fan temperature setting
0400=>(spm_FANT_xxxx)FAN_On_Temp (0400 = 40 degrees C)
 Serial number setting
000000000=>(spm_SNUM_xxxxxxxxx) SERIAL NUMBER
 MP3 type setting
0003=>(spm_MPOP_000x) MP3 MUSIC Option SET!!
0: Different music played each capture mode
1: Same music played each capture mode
2: Beep sound
3: Beep&AutoReturn sound(default)
 MP3 option settings
0001=>(spm_MPEN_000x) MP3 Player board SET!!
MP3 volume setting
0074=>(spm_VOLU_00xx) MP3 Player board SET!!(1~82)
~~~~~~~~~~~~~~~~~~~~~~~~~~~~
 Number of exposures per mode
01855=>(spm_GCNT)PANO_CAPTURE_CNT
00898=>(spm_GCNT)CEPH_CAPTURE_CNT
00665=>(spm_GCNT)ARCT_CAPTURE_CNT ct/ent
 Rotator initialization option when exposure the CEPH
0001=>(spm_MRTP_x)MODE_RESET_TYPE
