3.2 Software overview
The following figure shows initial view of imaging software running on the PC.
1. Progress bar:
Shows the progress status, with a graph, during imaging and image processing
2. Window for image:
Shows the captured image on real time. The window shows a reference-only drawing of
the image
We do not endorse the company’s opinion by mentioning the specific
model. This model is mentioned here for its stability and dependability
during our test with the equipment for a long period of time
For operating the PaX-Primo i, primarily all the operations are carried out on
the Touch pad screen. And this program runs in passive way, just
displaying images acquired. That is, this works as an image viewer.
1
2
3
4
5
6
7
8
9 10
