34
Chapter 5 Acquiring images
5.1 Acquiring Standard Panoramic image
Before acquiring image, make sure that you have:
z Reset a rotating unit of equipment to starting position for new entry.
z Selected the patient record you have created.
z Accessed the main program on touch pad screen to control the equipment.
z Have the imaging capture software on PC.
5.1.1 Preparing the unit and setting the acquisition parameters
From the touch pad panel, do the following procedures to prepare the parameters for a specific
patient and mode.
1. From the main screen of the LCD, touch the Standard button to have the next screen.
2. Select the resolution with which image is to be taken, Normal or High.
3. Select the patient type.
