3. Then after all the initialization processing inside the LCD modules completed, the LCD
returns to the main screen and announcement that capturing image is ready is heard.
5.1.4 Launching the exposure
To launch the X-ray emission, do the following steps.
1. Leave the X-Ray room and close the door. From outside of the x-ray room, you must
consistently monitor and pay attention to the patient during acquisition.
2. Launch X-ray using the exposure switch. Press and hold it until the end of acquisition.
Observe the LED lamp on top of the system, as it should turn orange, indicating X-ray
emission.
USB itself is not provided with the PaX-Primo i. Thus it is recommended
that the USB with following specification be mandatory to use.
Type : USB Flash Drive
Write Specification : USB 2.0
In cases of any problems, release the exposure switch button or press the
red emergency stop button on the column. (See the following figure)
