68
11. The horizontal laser beam, located at
the side of the column, can be adjusted
up or down to accommodate different
head sizes. This is done by manually
moving the horizontal laser beam lever
up or down.
12. Using the temple support wheel button,
adjust the temple supports to fit snugly
on either side of the patient’s head.
The patient’s head should be
immobilized. The temple support
wheel button is located at the front of
the patient support rest.
13. Have the patient close their lips and keep their tongue positioned towards the palate
throughout the exposure cycle.
14. For a patient with no teeth, the vertical laser beam should be positioned on the patient’s
mid-sagittal line. The horizontal laser beam should be aligned along the Frankfort plane.
Align the canine beam on the fold on the side of the nose.
