POS App Guide DIM Installation Examples
47
Figure 28. TLS-450/TLS-450PLUS Meter Stand Application Using 1871/7697 Series Pulser/Totalizer
MECHANICAL DISPENSER INTERFACE MODULE
MDIM
L1
N
NC
NC
P1
P2
P3
P4
P5
P6
P7
P8
P9
P10
P11
P12
120 VAC
INPUT RATING
120 VAC MAX
0 15 AMP MAX
GALLONS
769780-008
Pulse Transmitter
Metal Divider Plate
Barrier
No. 7859
"J" Box
Explosion Proof
Low Voltage Area
Orange
White
401-2.eps
Black
115 Vac Line (BLK)
Metal Conduit
V
00000
#14 AWG
(7 x 36 Stranded Wires,
Gas & Oil Resistant)
Meter Register
Neutral (WHT)
Typical Electric
Wiring Trough
