Appendix A: Site EVR/ISD Equipment Location Worksheet Multi-Hose Fueling Position Dispensers
A-4
Multi-Hose Fueling Position Dispensers
1
Each hose must have a unique number (1 - 99).
2
This is the Fuel Position Label which is the visible number on the outside of the dispenser (1 -2 digits).
3
The hose label is the grade.
4
The AFM ID number associated in Device Setup.
5
This is the serial number on the Air Flow Meter (1 per dispenser).
6
This is the AFM label entered in Device Setup (1 per dispenser and must be in the format shown, e.g., AFM FP1&2 - where 1 and 2 refer to
the one [or two] numbers on the outside of the dispenser).
7
After you have entered the contents of columns 1 - 5 enter as needed in Hose Settings setup, you now must follow Assist Mode Mapping
procedure and dispense from each hose. Enter a check in this column following a dispense from the hose.
FILL OUT - USE TO SETUP HOSE TABLE
Assist Mode
Check List
Hose
ID
1
FP
2
Hose
Label
3
AFM ID
4
& AFM Serial Number
5
AFM Label
6
Product
Dispense
7
AFM FP__&__
AFM FP__&__
To Next Page
