21
Setup Vapor Recovery Setup
Hose Mapping - Assisted Mode
1. Touch Menu>Setup>Vapor Collection>Hose Mapping (Figure 27). Touch Hose Mapping to access the Vapor
Collection Hose Mapping setup screen (see example in Figure 28).
Figure 27. Accessing Vapor Collection Hose Mapping Setup Screen
Figure 28. Vapor Collection Hose Mapping Setup Screen
2. Assisted mapping is easier on a site with previous events recorded on all fuel meters. However, we recommend
that you shutdown dispensing during assisted hose mapping. Ensure that all Hoses are not Locked. Touch the
Actions button and select Unlock All (see Figure 29).
If there is a hose you do not want to map at this time, lock that hose. You can map that hose
position later.
