Figure 9.2
SHLD2 Source Holder - Limit Switch
Number Component Material
1 Type Label - Source 316
2 Cover Plate 316
O-ring (beneath cover plate) FKM
3 Housing 316
4 Mounting Plate 316
5 Housing - Limit Switch Zinc Die Casting
6 Shutter - Limit Switch 304
7 Screw 316
8 Shutter Handle 316
9 Safeguard Cable 304, Plastic-coated (Vinyl)
10 Safety Screw 316
11 Screw (torx tamper-resistant) 304
