Figure 9.3
SHLD2 Source Holder - Interlock Safety Switch
Number Component Material
1 Type Label - Source 316
2 Cover Plate 316
O-ring (beneath cover plate) FKM
3 Housing 316
4 Mounting Plate 316
5 Housing - Safety Switch with Locking
Rod
Lock provided by customer
6 Screw 316
7 Shutter Handle with Interlock Locking
Sleeve
316
8 Safeguard Cable 304, plastic-coated (Vinyl)
9 Safety Screw 316
10 Screw (torx tamper-resistant) 304
