10
3 Product description
VEGAPULS 21 • Two-wire 4 … 20 mA/HART
58351-EN-191014
The packaging consists of environment-friendly, recyclable card-
board. For special versions, PE foam or PE foil is also used. Dispose
of the packaging material via specialised recycling companies.
Transport must be carried out in due consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or con-
cealed defects must be appropriately dealt with.
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
•
Not in the open
•
Dry and dust free
•
Not exposed to corrosive media
•
Protected against solar radiation
•
Avoiding mechanical shock and vibration
The permissible storage and transport temperatures can be found in
chapter "Supplement - Technical data - Ambient conditions"
3.5 Accessories
Screwedangesareavailableindierentversionsaccordingtothe
following standards: DIN 2501, EN 1092-1, BS 10, ASME B 16.5,
JIS B 2210-1984, GOST 12821-80.
Welded sockets are used to connect the sensors to the process.
Threaded adapters enable simple adaptation of sensors with stand-
ardthreadedttings,e.g.toprocess-sidehygieneconnections.
The mounting accessories include e.g. bracket and mounting bracket
and are used for stable mounting of the sensor at the measuring
point. The parts are available in various versions and sizes.
Transport
Transpor
t inspection
Storage
Storage and transport
temperature
Flanges
Welded sockets and
adapters
Mounting accessories
