7 Setup with smartphone/tablet (Bluetooth)
VEGAPULS 21 • Two-wire 4 … 20 mA/HART
58351-EN-191014
The message "Waiting for authentication" is displayed on the smart-
phone/tablet.
After connection, the sensor adjustment menu is displayed on the
respective adjustment instrument.
If the Bluetooth connection is interrupted, e.g. due to a too large
distance between the two devices, this is displayed on the operating
device. The message disappears when the connection is restored.
Parameter adjustment of the device is only possible if the parameter
protection is deactivated. When delivered, parameter protection is
deactivated by default and can be activated at any time.
It is recommended to enter a personal 6-digit device code. To do this,
go to menu "Extended functions", "Access protection", menu item
"Protection of the parameter adjustment".
7.3 Parameter adjustment
The sensor adjustment menu is divided into two areas, which are
arranged next to each other or one below the other, depending on the
adjustment tool.
•
Navigation section
•
Menu item display
The selected menu item can be recognized by the colour change.
Fig. 20: Example of an app view - Setup sensor adjustment
Entertherequestedparametersandconrmviathekeyboardorthe
editingeld.Thesettingsarethenactiveinthesensor.
Close the app to terminate connection.
Connected
Change device code
Enter parameters
