P-3
Part #1169256 08/2010
Diagnostics:
See inner door of vendor or Troubleshooting section for errors and how to clear them.
Coin Payout:
Coin Payout Mode allows the operator to ‘test’ for proper operation of the changer tubes.
1. Press Button 4 to enter into “Coin Payout” mode.
2. Press Button 2 or 3 to scroll to desired denomination.
3. Press Button 4 to dispense displayed denomination.
4. Press Button 1 to exit mode.
Tube Fill:
Allows you to fi ll coin tubes via the external coin insert. This is the recommended way to fi ll the
coin tubes because the control board is able to keep an accurate count of the coins.
1. Press Button 4 to enter into “Tube Fill” mode.
2. Insert coins into coin insert slot and the controller will “count” the number of coins going
into the coin mechanism.
Test Mode Vending:
Allows you to test vend a column, jog a column, display, test selection switches, and relays.
1. At “Test Mode” press Button 4. Display will “Test Mode -Vending”.
2. Press Button 2 or 3 to scroll to desired column.
3. Press Button 4 to vend.
a. If motor vends OK, DISPLAY will read “
Test Mode - Vending Motor OK
”
b. If motor does not test OK on one of the following messages will appear:
- “Test Mode - Vending Fail - Column Jam”
- “Test Mode - Vending Fail - No Connection”
- “Test Mode - Vending Fail - High Current”
Test Mode Jogging a Column:
2. At “Test Mode - Vending”, press Button 2 or 3 to scroll. Display will read “Test Mode - Jog.”
3. Press Button 4 and display will read “Column 1.”
4. Press Button 2 or 3 to scroll to desired column.
5. Press Button 4 to enter into column and display will read “ Column X Forward” with X being
the desired column.
6. Press Button 2 or 3 to scroll between “Forward” or “Reverse.”
7. Press Button 4 to move/jog the motor in the desired position.
8. Press Button 1 to exit this mode.
3. Press button 1 to exit mode.
4. Press button 1 to exit mode.
1. At “Test Mode” press Button 4.
