P-4
Part #1169256 08/2010
Test Mode Selection Switch Testing:
2. At “Test Mode - Jog” press Button 2.
3. “Test Mode Switches” will be displayed. Press Button 4.
4. Press desired selection switch to be tested.
5. To exit press Button 1 and hold for 3 seconds.
Test Mode Display:
Allows you to verify that all of the characters on the display illuminate.
2. Press Button 2 to scroll until display reads “Test Mode - Display.” Press Button 4.
3. All of the characters on the display should illuminate.
4. Press Button 1 to exit mode.
Test Mode Relays:
Allows you to test the compressor, evaporator fan, lights and heater.
2. Press Button 2 to scroll until display reads “Test Mode - Relays” and press Button 4.
3. Press Button 2 or 3 to advance through sub-modes.
4. Press Button 4 at “Compressor” prompt to test compressor.
5. Press Button 4 at “Fan” prompt to test evaporator fan.
6. Press Button 4 at “Light” prompt to test lighting system.
7. Press Button 4 at “ Heater” prompt to test optional heater.
8. Press Button 1 to exit sub-modes.
Cash Data:
This Mode allows you to retrieve historical information regarding the money accepted by the
vendor. To clear the individual selection cash data, you must have the
MIS Auto Reset
in the
“Confi guration” mode turned to ON.
1. When “Cash Data” is displayed press Button 4. The non-resettable historical data is
displayed.
2. Press Button 2 or 3 to display resettable individual selections.
3. To reset historical data, make sure the
MIS Auto Reset
is turned ON in the confi guration mode.
4. Press Button 1 to exit mode.
Sales Data:
This Mode allows you to retrieve historical information regarding the number of units sold by
vendor. To clear the individual selection sales data, you must have the
MIS Auto Reset
in the
“Confi guration” mode turned ON.
1. When “Sales Data” is displayed, press Button 4. The non re-settable historical data is
displayed.
2. Press Button 2 or 3 to display resettable individual selections.
3. To reset historical data, make sure the
MIS Auto Reset
is turned ON in the confi guration mode.
4. Press Button 1 to exit mode.
9. Press Button 1 to exit mode.
1. At “Test Mode” press Button 4.
1. At “Test Mode” press Button 4.
1. When “Test Mode” is displayed press Button 4.
