TD-5
Part #1169256 09/2008
CHAMELEON TRADE DOOR (CONTINUED)
ITEM
NO
MODEL NUMBER 721 821
HARDWARE
DESCRIPTION QTY
REQ
PART NO. PART NO.
1 HINGE - INNER DOOR, MALE 2 1121287 1121287 F
2 MOUNTING BRACKET - CONTROLLER 1 1077716 1077716 H
3 STAND OFF 7 1121740 1121740
4 PCBA VEC 12.1 CONTROLLER 1 1167867 1167867
5 PCBA COVER PANEL 1 1123049 1123049 H
6 PLATE, DBV PLUG, UPPER 1 1143498 1143498 F
7 COIN INSERT CHUTE 1 1121066 1121066 U
8 ASY, COOIN RETURN LEVER 1 1143372 1143372 F
9 DOOR BUMPER 2 1036912 1036912
10 DELIVERY HOPPER ASSEMBLY 1 1149325 1149325 D, K
11 LAMP - 17W T-8, 24” 2 1130637 1130637
12 LAMP - 32W T-8, 48” 2 1130637-2 1130637-2
13 BKT, LIGHT, UPPER 2 1150387 -
14 BULB, HOLDER, PLUNGER 4 1151265 1151265
15 RAIN GUTTER 1 1121204 1121204 K
16 PNL, SHR, UPR/LWR, 39” 4-BLB 2 1123917 1123917 K
17 LAMP BRACKET LOWER PROFILE 4 1151367 1151367 F
18 PNL, SHR, MIDDLE 1 1122308 1122308
19 LAMP EXTENSION BRACKET 2 1150259 -
20 BRKT, LAMP, HO, EXT 2 1143528 1143528
To Next Page
