Venmar S10 ERV - Lectrical Onnection to; Electrical; Electrical Connection to

16
3. CONTROLS (CONT'D)
3.6 ELECTRICAL CONNECTION TO WALL CONTROLS (CONT'D)
3.6.1 E
LECTRICAL CONNECTION TO ALTITUDE
(S10 ERV
PLUS AND S10N ERVPLUS UNITS ONLY) OR
P
LATINUM (70E+ AND 70EN+ UNITS ONLY) MAIN WALL
CONTROL
3.6.2 ELECTRICAL CONNECTION TO DECO-TOUCH
M
AIN WALL CONTROL (S10 ERVPLUS,
S10
N ERVPLUS, S10 ERV, S10 ERV ECM, 70E+,
70EN+, 70E AND 70E ECM UNITS ONLY)
3.6.3 E
LECTRICAL CONNECTION TO SIMPLE-TOUCH
CONSTRUCTO (S10 ERVPLUS AND S10N ERVPLUS
UNITS ONLY) OR SIMPLE-TOUCH BRONZE (70E+ AND
70EN+ UNITS ONLY) MAIN WALL CONTROL
3.6.5 ELECTRICAL CONNECTION TO CONSTRUCTO
OR BRONZE MAIN WALL CONTROL (ALL UNITS)
NO C NC I OC OL Y R G B
VE0181
SMART
SET
MODE
PREF
NO C NC I OC OL Y R G B
VE0250
NO C NC I OC OL Y R G B
VE0187
3.6.6 ELECTRICAL CONNECTION TO OPTIONAL AUXILIARY WALL CONTROLS
NOTE: If an optional auxiliary wall
control is activated and
then, the Dehumidistat is
being activated, this one will
override the auxiliary wall
control commands.
Once the wall control(s) connections have been made and checked, close the unit door.
NOTE: For information about the operation of the wall controls, refer to the Main and auxiliary wall controls user guide (included
with your unit and also available at www.venmar.ca or www.vanee.ca).
NO C NC I OC OL Y R G B
PUSH-BUTTON TIMERS
60-MINUTE
CRANK TIMER
DEHUMIDISTAT
VE0296A
NO C NC I OC OL Y R G B
B G
G
B
Y
VE0328A
Y
MAIN WALL CONTROLS
SIMPLE-TOUCH CONSTRUCTO
AND SIMPLE-TOUCH BRONZE
REAR VIEW
3.6.4 ELECTRICAL CONNECTION TO LITE-TOUCH
CONSTRUCTO OR LITE-TOUCH BRONZE MAIN WALL
CONTROL (ALL UNITS)
NO C NC I OC OL Y R G B
B G
G
B
Y
VE0328A
Y
MAIN WALL CONTROLS
LITE-TOUCH CONSTRUCTO,
OR LITE-TOUCH BRONZE,
REAR VIEW
