HE250 - Installation and Operation Manual 9
2.2 General Features
Maximum log length 21 in (533 mm) east-west*
Flue outlet diameter 6 in (152 mm)
Chimney diameter 6 in (152 mm)
Type of chimney CAN/ULC S629, UL 103 HT (2100 °F)
Baffle material C-Cast
Approved for alcove installation Not approved
Approved for mobile home installation
‡
Not approved
Type of door Single, glass with steel frame
Type of glass Ceramic glass
Blower Included (up to 176 CFM)
Particulate emission standard EPA / CSA B415.1-10
USA standard (safety) UL 127
Canadian standard (safety) ULC-S610
**
East-west: through the door you see the longitudinal sides of the logs; north-south: through the door you see the tips of the
logs.
‡
Mobile home (Canada) or manufactured home (USA): The US department of Housing and Urban Development describes
“manufactured homes” better known as “mobile homes” as followed; buildings built on fixed wheels and those transported on
temporary wheels/axles and set on a permanent foundation. In Canada, a mobile home is a dwelling for which the manufacture
and assembly of each component is completed or substantially completed prior to being moved to a site for installation on a
foundation and connection to service facilities and which conforms to the CAN/CSA-Z240 MH standard.
8”/203mm HOT AIR GRAVITY DISTRIBUTION KIT (2)
