5.2 Electrical cabinets
5.2.1 Main control cabinet:
The main control cabinet can be found under the cover in figure 13. After unscrewing
(four M6 bolts) and releasing the painted cover the main electric cabinet will appear.
Figure 13
By removing the elastic holders it will give access to the main control cabinet (Figure 14 ).
Figure 14
