13.3 Maintenance details
HYDRAULIC
Oil volume :10,0 liter
Oil quantity :(applications of -10° to + 50°) UNIVIS 32
GUIDED BEARINGS
Multi duty grease EP2 (example Shell alvania EP2/ Esso beacom EP2)
SLIDEWAYS Racks
Only clean
Slideways Tubes inside
Only clean the surface
TURNTABLE
Multi duty grease EP2 (example Shell alvania EP2/ Esso beacom EP2)
13.4 Torque index Tension
Dimensions
thread
Of torque for bolt with thread in hermetically
ISO Nm
Hex bolt
Class 8.8
Hex bolt
Class 10.9
Hex bolt
Class 12.9
M4
2,8
4,0
4,9
M5
5,7
7,9
9,5
M6
9,7
13,7
16,2
M8
23,5
33,3
39,2
M10
47,1
65,7
79,4
M12
81,4
114,7
137
M14
130
181
216
M16
196
280
333
M18
270
382
461
M20
382
539
647
M22
519
730
873
M24
662
932
1118
M30
1324
1863
2236
Table 5
