Veromatic MBE01 - PP-00581 Main I;O Board

51
EN
9.1.1 PP-00581 main I/O board
Part Description
1 MDB (pay system)
2 Connection PP-00880
3 USB
4 Telemetry
5 Power
6 24V output
7 Sensors
8 LED
9 Boot button
10 Jumper
11 Battery
12 Fan
13 Heating element steering
14 230V output
15 Fuse (2A)
