1-5. View of the Optional Modules
In the switch, Ports 13~16 include two types of media --- TP and SFP Fiber (LC, BiDi…); this port
supports 10/100/1000Mbps TP or 1000Mbps SFP Fiber with auto-detected function. 1000Mbps SFP Fiber
transceivers are used for high-speed connection expansion; nine optional SFP types provided for the
switch are listed below:
⎯ 1000Mbps LC, MM, SFP Fiber transceiver
⎯ 1000Mbps LC, SM 10km, SFP Fiber transceiver
⎯ 1000Mbps LC, SM 30km, SFP Fiber transceiver
⎯ 1000Mbps LC, SM 50km, SFP Fiber transceiver
⎯ 1000Mbps LC, SM 70km, SFP Fiber transceiver
⎯ 1000Mbps LC, SM 110km, SFP Fiber transceiver
⎯ 1000Mbps BiDi, TX=1310nm, SM 20km, SFP Fiber WDM transceiver
⎯ 1000Mbps BiDi, TX=1550nm, SM 20km, SFP Fiber WDM transceiver
⎯ 1000Mbps LC, SM 10km, SFP Fiber transceiver with DDM
Fig. 1-4 Front View of 1000Base-SX/LX LC, SFP Fiber Transceiver
Fig. 1-5 Front View of 1000Base-LX BiDi SFP Fiber Transceiver
