4-3. Monitoring
There are six functions contained in the monitoring function.
4-3-1. Statistics Overview
The function of Statistics Overview collects any information and provides the counting summary
about the traffic of the port, no matter the packet is good or bad.
In the Fig. 4-25, the window can show all ports’ counter information at the same time. If the
counting is overflow, the counter will be reset and restart counting.
Function name:
Statistics Overview
Function description:
Display the summary counting of each port’s traffic, including Tx Bytes, Tx Frames, Rx Bytes, Rx
Frames, Tx Errors and Rx Errors.
Parameters description:
Tx Bytes:
Total transmitted bytes.
Tx Frames:
The counting number of the packet transmitted.
Rx Bytes:
Total received bytes.
Rx Frames:
The counting number of the packet received.
Tx Errors:
Number of bad packets transmitted.
Rx Errors:
Number of bad packets received.
