Vertiv Challenger 3000 User Manual

Coil Section
September 2011 - 9 -
4.4. 5T Downflow
4.4.1. Chilled Water
Item
Part #
Description
Quantity
1
136977G1
COIL CW ASSY C3000 5T D
1
136977G3P
COIL CW ASSY C3000 5T D HERE
1
136689G1
COIL CW ASSY 5T W/HWRH D
1
3
136778G1
PAN DRAIN COIL C3000
1
4.4.2. R-407C
Item
Part #
Description
Quantity
1
194598G2
COIL ASSY 5T DX D
1
194598G4P
COIL ASSY 5T DX D RIF W/HERE
1
195583G2
COIL DX ASSY 5T D HW/HG RIFLED
1
195586G7
COIL 5T DF RIF GLYCOOL C3000
1
195677G2P
COIL 5T GLYCOOL D RIF W/LIBC
1
33
136778G1
PAN DRAIN COIL C3000
1
99
128158P3
VALVE EXP 1/2X5/8X1/4ODF
1
