Vertiv Challenger 3000 - Liquid Line Assembly 3 T D;U 3000 (141143 G1); Liquid Line Assembly ½ (196665 G1-G2)

Piping Section
September 2011 - 67 -
11.3.2. Liquid Line Assembly 3T D/U 3000 (141143G1)
Item
Part #
Description
3T
5T
1
P-3870
INDICATOR LIQUID 3/8 ODF
1
1
2
P03-0030
FILTER/DRIER 3/8ODF SLDR
1
1
11.3.3. Liquid Line Assembly ½ (196665G1-G2)
Item
Part #
Description
3T
5T
2
187933G2
VALVE ACC BODY 1/4 EXT1" BEAD
1
1
3
P02-0290
VALVE CORE REFRIGERANT
1
1
