Piping Section
September 2011 - 49 -
11. Piping Section
11.1. Chilled Water
11.1.1. Upflow: Chilled Water
2-Way
3-Way
Item
Part #
Description
2W
3W
3
159009P1
VALVE 1" 2WAY UNION BODY
1
159010P1
VALVE 1" 3WAY UNION BODY
1
9
146352G1
ACTUATOR ASSY SP SML 92" WH
1
1
17
127998P2
SW FLOW ASSY 1-1/8"
1
61
P02-0290
VALVE CORE REFRIGERANT
2
2
62
187933G2
VALVE ACCESS BODY 1/4X SWT
2
2
