Vertiv Challenger 3000 User Manual

Coil Section
September 2011 - 5 -
4. Coil Section
4.1. 3T Upflow
4.1.1. Chilled Water
Item
Part #
Description
Quantity
1
136653G4
COIL CW ASSY C3000 U
1
136653G2P
COIL CW ASSY C3000 U HERESITE
1
136688G4
COIL CW ASSY 3T W/HWRH U
1
2
136631G1
PAN DRAIN COIL U C3000
1
4.1.2. R-407C
Item
Part #
Description
Quantity
1
195621G4
COIL DX ASSY 3T HW/HG U RIF
1
195617G4
COIL ASSY 3T DX U RIFLED
1
195617G2P
COIL ASSY 3T DX U RIFLED
1
2
136631G1
PAN DRAIN COIL U C3000
1
99
128157P1
VALVE EXP 1/2X5/8X1/4ODF 3T
1
