Piping Section
September 2011 - 79 -
11.5.2. Downflow
Item
Part #
Description
3T
5T
1
196835G1
Suction Line Assembly on Page 73
5
196836G1
Liquid Line Assembly on Page 74
13
1A23985P1
VALVE SOLND 1/2" NC 24V 50/60
1
1
56
176251G4
TXV+DISTRIBUTOR ASSY 5T C3K DF
1
