Vertiv Challenger 3000 User Manual

Challenger 3000 w/ iCOM
- 62 - September 2011
Item
Part #
Description
3T
5T
5
W-0330
SEAL ROTOLOCK 1-1/4"X12"TEFLON
1
1
6
141141G1
Hot Gas ASM on Page 64
7
197191G1
Discharge Line Assembly 3T D on Page 64
16
F02-371A
SUPPORT VALVE TEV
1
1
R-407C
Item
Part #
Description
3T
5T
1
141104G3
Suction Line Assembly 3/5T U on Page 62
2
141142G1
Liquid Line Assembly 3T A D/U on Page 63
3
141127G1
Discharge Line Assembly 3/5T U on Page 64
4
W-0320
SEAL ROTOLOCK 1"X14" TEFLON
1
1
5
W-0330
SEAL ROTOLOCK 1-1/4"X12"TEFLON
1
1
7
179738G2
Discharge Line Assembly on Page 43
41
P-1100
REDUCER CU CXC 7/8"X5/8"
1
44
196265G2
Digital Solenoid Valve Assembly on Page 62
52
P02-0290
VALVE CORE REFRIGERANT
1
1
