Vertiv™ | Liebert® DM | User Manual 48
Electrical Installation
Enlarge view of Power Output Terminal for DM 07 kW/12 kW
No. Description No. Description
1 Power output terminal 6 N line terminal
2 Cable clamp 7 A line terminal
3 Cable hole 8 B line terminal
4 Outdoor terminal 9 C line terminal
5 PE terminal
Figure 3-1 Power Connection of Outdoor Unit (7 kW and 12 kW)
