Vertiv | Liebert® EDGE | Installer/User Guide 11
2.4.2. Installing a 2U or 3U Model
CAUTION: Do not use the mounting brackets to lift the unit. Only use the mounting brackets to
secure the UPS to the rack.
See Figure 2.5 below, to install the unit.
Figure 2-5 Installing the UPS in a rack
ITEM DESCRIPTION
1 Attach the brackets to the UPS.
2 Install the supplied rack kit into the rack.
3
Install the UPS in the rack.
2.4.3. Installing a Mini Tower (MT) Model
Place the unit upright, on its feet without blocking air inlets.
2.5. Connecting Loads
The UPS has non-programmable and programmable outlets. Plug your critical equipment (such as computer,
monitors, etc.) into the non-programmable outlets and your less-critical equipment (such as printers and other
less-often used peripherals) into the programmable outlets.
