Vertiv | Liebert® EDGE | Installer/User Guide
27
Threshold of when power returns for (min)
• Enable
• Disable (default)
Sets the turnning on waiting time of programmable outlet when power returns.
• 0 - 30 minutes (default of 0)
3.2.5. Control Screen
The Control screen oers UPS-control options.
To adjust the UPS controls:
3. At the main menu, select the Control icon, and press Enter.
4. Use the arrow buttons to move the cursor to the option, then press Enter to select the control.
Control Options
Turn on/o
Opens the dialog to change operating modes.
Mute/Unmute audible alarm
Silences or un-silences the audible alarm.
Start/Stop battery manual test
Starts the battery self test manually. If the manual self test is already running, stop the self test.
Clear faults
Clears displayed faults after the issue causing the fault is resolved.
Reset power statistics
Resets the values tracked to calculate the Eiciency graph.
3.2.6. Log Screen
The Log Screen oers tabs that list the current alarms and the alarm/event history. Table 3-2, describes the
alarm messages you may see in the logs.
To view the logs:
1. At the main menu, select the Log icon, and press Enter.
2. Use the arrow buttons to move the cursor left/right and select a tab, then press Enter to display the log for
the selected tab.
