Vertiv | Liebert® EDGE | Installer/User Guide 41
Chapter 5: SPECIFICATIONS
Table 5-1 Specifications, EDGE-500IRM1U,EDGE-1000IRM1U and EDGE-1500IRM1U
MODEL EDGE-500IRM1U EDGE-1000IRM1U EDGE-1500IRM1U
Power Rating @ 230V 500VA / 450W / 2.2A 1000VA / 900W / 4.4A 1500VA / 1350W / 6.7A
Dimensions, D×W×H, in. (mm)
Unit Dimensions,
W x D x H, mm
438 x 380 x 44 438 x 480 x 44 438 x 600 x 44
Shipping Dimensions,
W x D x H, mm
550 x 620 x 200 570 x 700 x 200 780 x 570 x 200
Weight, lb.(kg)
Unit Weight, kg 11.3 16.1 22.8
Shipping Weight, kg 17.3 23.4 30.5
Input
Voltage Input Range (with
battery operation)
0 to 300 VAC
Voltage Input Range
(without battery operation)
144 to 290 VAC
Input Voltage Measurement
Tolerance
±5%
Nominal Voltage Setting 200 / 208 / 220 / 230 / 240 VAC
High Line Buck to Battery 241 / 251 / 266 / 278 / 290 VAC
High Line Battery to Buck 235 / 245 / 260 / 272 / 284 VAC
High Line Normal to Buck 220 / 229 / 242 / 253 / 264 VAC
High Line Buck to Normal 215 / 224 / 237 / 248 / 259 VAC
Low Line Boost1 to Normal 185 / 192 / 203 / 212 / 221 VAC
Low Line Normal to Boost1 180 / 187 / 198 / 207 / 216 VAC
Low Line Boost2 to Boost1 160 / 166 / 176 / 183 / 191 VAC
Low Line Boost1 to Boost2 155 / 161 / 171 / 178 / 186 VAC
Low Line Battery to Boost2 155 / 161 / 171 / 178 / 186 VAC
Low Line Boost2 to Battery 144 / 150 / 158 / 166 / 173 VAC
Frequency Input Range
45 to 65 Hz
Autodetect 50 / 60 Hz
Battery to Normal comeback at 50Hz: 47 to 53Hz
Battery to Normal comeback at 60Hz: 57 to 63Hz
Internal Rear-panel Input
Breaker Rating
5 A 8 A 10 A
Input Surge Protection EN61000-4-5; Line to Line: Level 2; Line to Earth: Level 3
Input Power Receptacle IEC 320 C14
