Vertiv | Liebert® EDGE | Installer/User Guide 13
Figure 2-6 Connecting External Batteries
ITEM DESCRIPTION
1 Connection to second connector on external battery cabinet for additional battery cabinets.
2 Connection from UPS to single/rst external battery.
3 Connect to next external battery.
4 Connection to UPS.
