MODEL EDGE-500IRM1U EDGE-1000IRM1U EDGE-1500IRM1U
Power Rating @ 230V 500VA / 450W / 2.2A 1000VA / 900W / 4.4A 1500VA / 1350W / 6.7A
Compliance CE, CB Report
Safety IEC/ EN62040-1:2008+A1:2013
RFI/EMI EN62040-2:2006(C1)
Transportation ISTA 2A
Table 6.1 Specifications, EDGE-500IRM1U,EDGE-1000IRM1U and EDGE-1500IRM1U (continued)
MODEL EDGE-750IMT EDGE-1000IMT EDGE-1500IMT
Power Rating @ 230V 750VA / 675W / 3.3A 1000VA / 900W / 4.4A 1500VA / 1350W / 6.7A
Dimensions, D×W×H, in. (mm)
Unit Dimensions, W x D x H, mm 145 x 370 x 220 145 x 480 x 220
Shipping Dimensions, W x D x H,
mm
230 x 450 x 325 230 x 570 x 325
Weight, lb.(kg)
Unit Weight, kg 11.2 11.8 18.2
Shipping Weight, kg 12.6 13.2 20
Input
Voltage Input Range (with battery
operation)
0 to 300 VAC
Voltage Input Range (without
battery operation)
144 to 290 VAC
Input Voltage Measurement
Tolerance
±5%
Nominal Voltage Setting 200 / 208 / 220 / 230 / 240 VAC
High Line Buck to Battery 241 / 251 / 266 / 278 / 290 VAC
High Line Battery to Buck 235 / 245 / 260 / 272 / 284 VAC
High Line Normalto Buck 220 / 229 / 242 / 253 / 264 VAC
High Line Buck to Normal 215 / 224 / 237 / 248 / 259 VAC
Low Line Boost1 to Normal 185 / 192 / 203 / 212 / 221 VAC
Low Line Normalto Boost1 180 / 187 / 198 / 207 / 216 VAC
Low Line Boost2 to Boost1 160 / 166 / 176 / 183 / 191 VAC
Low Line Boost1 to Boost2 155 / 161 / 171 / 178 / 186 VAC
Low Line Battery to Boost2 155 / 161 / 171 / 178 / 186 VAC
Low Line Boost2 to Battery 144 / 150 / 158 / 166 / 173 VAC
Table 6.2 Specifications, EDGE-750IMT, EDGE-1000IMT and EDGE-1500IMT
6 Specifications
45
Liebert® EDGE Installer/User Guide
