Upon receipt, check the items received against the order and shipping manifest. If any parts are missing or has noticeable
damage, please notate this on the proof of delivery and contact your local Vertiv representative or visit
http://www.Vertiv.com/en-us/support/.
The UPS ships on a pallet and is equipped with casters that permit two or more people to roll it off the pallet for installation.
Move the palleted UPS as close as possible to the installation location before removing packing material or loosening shipping
brackets.
NOTICE
The casters on the UPS are for moving short distances. Move the pallet as close as possible to the installation
site before taking the UPS off the pallet. Plan the unloading procedure and route to the final location to minimize
the distance that the UPS must be rolled on casters and to avoid large cracks and uneven flooring. Major shocks
while moving the UPS over large cracks can loosen internal connections and otherwise damage the unit.
During unpacking:
• Inspect the UPS for damage. If you find any damage, please document and photograph the damages and notify
your local Vertiv representative.
• Check the accessories and model numbers against the delivery list. If you find any problem, notify your local
Vertiv representative immediately.
3.2.1 Removing the UPS from the shipping pallet
1. Using a forklift, pallet jack, or other lifting device, move the packaged unit as close as practical to the intended
installation location.
2. Remove the protective packing.
3. Locate the included accessories in their packed location on top of the UPS, and set them aside.
4. Unbolt the shipping brackets from the pallet with a 16 mm(5/8 in.)wrench or socket:
• Remove the front, lower panel from the UPS, and unbolt the front shipping bracket.
• Unbolt the shipping bracket from the rear of the UPS.
• Retain the brackets to secure the installed UPS to the floor, if required.
5. Raise the leveling feet so that they will not interfere when moving the UPS.
6. Place the ramp onto the pallet at the front of the UPS, and gently roll the UPS down the ramp to the floor then
into the installation position.
7. Lower the leveling feet to fix the UPS in the location.
3.3 Connecting Power Cables
WARNING! Risk of electrical shock. Can cause property damage, injury, and death.
The unit has several circuits that are energized with high DC and AC voltages. Check for voltage with both
AC and DC voltmeters before making contact and before working within the UPS. Only properly trained and
qualified personnel wearing appropriate, OSHA approved PPE should prepare for installation, install, and
maintain the equipment. When performing maintenance with any part of the equipment under power, service
personnel and test equipment must stand on rubber mats.
3 Installation and Commissioning Proprietary and Confidential ©2023 Vertiv Group Corp. 21
Vertiv™ Liebert® EXS Installer/User Guide
