Vertiv Liebert EXS - REPO Connection

Figure 3.3 Connection Terminal Access and Locations
Item Description
1 Wiring access cover plate
2 15-30 K
3 40 K
3 Installation and Commissioning Proprietary and Confidential ©2023 Vertiv Group Corp. 25
Vertiv™ Liebert® EXS Installer/User Guide
