Vertiv LIEBERT GXT5 Series User Manual

Maintenance56
WARNING! Risk of electric shock
Can cause equipment damage, injury and death. A battery can explode if the battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions included with the battery-pack.
Read all safety cautions before proceeding. A trained user can replace the internal battery pack when the UPS
is in a restricted access location (such as a rack or server closet). To obtain the appropriate replacement battery
pack(s), refer to Table 5-1 below, and contact your local dealer or Vertiv representative.
Table 5-1 Replacement Battery-pack Model Numbers
UPS MODEL NUMBER BATTERY PACK MODEL NUMBER QUANTITY REQUIRED
GXT5-5000IRT5UXLN
GXT5-192VBATKIT 1
GXT5-5000IRT5UXLE
GXT5-5000HVRT5UXLN
GXT5-6000IRT5UXLN
GXT5-6000IRT5UXLE
GXT5-8000IRT5UXLN
GXT5-192VBATKIT 1
GXT5-8000IRT5UXLE
GXT5-8000HVRT5UXLN
GXT5-10KIRT5UXLN
GXT5-10KIRT5UXLE
GXT5-10KHVRT5UXLN
GXT5-16KIRT9UXLN
GXT5-192VBATKIT 1
GXT5-16KIRT9UXLE
GXT5-20KIRT9UXLN
GXT5-20KIRT9UXLE
To replace a battery pack:
NOTE: The internal battery pack is hot-swappable. However, you must exercise caution because; during this
procedure, the load is unprotected from disturbances and power outages. Do not replace the battery while the
UPS is operating in Battery Mode. This will result in a loss of output power and will drop the connected load.
1. Press the button on the left-front of the UPS front panel, and pull the panel open, then, loosen and remove
the screw from the battery door, see Figure 5-1 on the next page.
2. Lay the battery door and screw aside for reassembly.
3. Grasp the battery handle, and pull out the battery pack, see Figure 5-1 on the next page.
4. Unpack the replacement battery pack, taking care not to damage the packaging to re-use when disposing
of the old battery.
5. Compare the new and old battery pack to make sure they are the same type and model. If so, proceed with
step 6. If they are dierent, stop and contact your Vertiv representative, or Technical Support, http://www.
Vertiv.com/en-us/support/.
