Vertiv LIEBERT GXT5 Series User Manual

Vertiv | Liebert® GXT5™ | Installer/User Guide 63
Chapter 7: Specications
Table 7-1 UPS Specications, 5-kVA and 6-kVA models
MODEL: GXT5- 5000IRT5UXLN* 5000IRT5UXLE 5000HVRT5UXLN* 6000IRT5UXLN* 6000IRT5UXLE
RATING
5000 VA/5000 W 6000 VA/6000 W
Dimensions, mm (in.)
Unit, WxDxH 430×630×217(16.9×24.8×8.5)
Shipping, WxDxH 646×816×520(25.4×32.1×20.5)
Weight, kg (lb)
Unit 70.8 (156) 71.1 (156.7) 70.8 (156)
Shipping 92(202.8) 89 (196.2) 92(202.8) 92(202.8) 89 (196.2)
Input AC Parameters
Operating Frequency, Nom. 50 or 60 Hz (factory-default is 50 Hz)
Factory-default VAC 230 VAC
User-congurable VAC
200/208/220/230/240 VAC
(Adjustable using operation/display conguration options)
Operating voltage range without
battery operation
176 – 288 VAC (100 – 176 VAC with power derating)
Maximum Allowable VAC 288 VAC
Input frequency without battery
operation
40 – 70 Hz
Input Power Connection PD5-CE6HDWRMBS PD5-CE6HDWRMBSU PD5-CE6HDWRMBS
Output AC Parameters
AC-AC Eiciency 94%
Factory-default VAC
Frequency
230 VAC, 50 Hz
Output Power Connection PD5-CE6HDWRMBS PD5-CE6HDWRMBSU PD5-CE6HDWRMBS
Waveform Sinewave
Main Mode Overload > 150% minimum 200 mS, 125 – 150% for 60 seconds; 105 – 125% for 5 minutes; ≤ 105% continuous
Internal Battery Charger
Charger Current, A 2.25 A (default), maximum 5 A
Battery Parameters
Type Valve-regulated, non-spillable, lead acid
Quantity x Voltage x
Rating
16 x 12V x 9.0AH
Battery Mfr./Part # 9AH; LEOCH/DJW12-9.0
Back-up time See Table 7-11 on page 72. See Table 7-10 on page 72.
Upper-limit selections +10%, +15%, +20%; default +10%.
Lower-limit selections -10%, -15%, -20%; default -15%
Disable-bypass operation When the input frequency prevents synchronous operation.
*Only these models are available in the ASIA PACIFIC region.

Vertiv LIEBERT GXT5 Series Specifications

General

Model	LIEBERT GXT5 Series
Product Type	UPS
Topology	Double Conversion Online
Display	LCD
Form Factor	Tower, Rackmount
Output Voltage	200/208/220/230/240 VAC
Output Frequency	50/60Hz ±0.1Hz (battery mode)
Typical Backup Time	Varies by model and load
Communication Ports	USB, RS-232
Operating Temperature	0°C to 40°C (32°F to 104°F)
Relative Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Certifications	UL, cUL, CE, RoHS
Battery Type	Valve Regulated Lead Acid (VRLA)
