Vertiv | Liebert® GXT5™ | Installer/User Guide 65
Table 7-2 UPS Specications, 8-kVA and 10-kVA models
MODEL: GXT5- 8000IRT5UXLN 8000IRT5UXLE 8000HVRT5UXLN 10KIRT5UXLN 10KIRT5UXLE 10KHVRT5UXLN
RATING 8000 VA/8000 W 10000 VA/10000 W
Dimensions, mm (in.)
Unit, WxDxH 430×630×217(16.9×24.8×8.5)
Shipping, WxDxH 646×816×520(25.4×32.1×20.5)
Weight, kg (lb)
Unit 74.5 (164.2) 75.5 (166.4) 74.5 (164.2) 75.5 (166.4)
Shipping 95 (209.4) 93 (205) 94 (207.2) 95 (209.4) 93 (205) 94 (207.2)
Input AC Parameters
Operating Frequency,
Nom.
50 or 60 Hz (factory-default is 50 Hz)
Factory-default
VAC
230 VAC
User- congurable
VAC
200/208/220/230/240 VAC
(Adjustable using operation/display conguration options)
Operating voltage
range without battery
operation
176 – 288 VAC (100 – 176VAC with power derating)
Maximum Allowable
VAC
288 VAC
Input frequency
without battery
operation
40 – 70 Hz
Input Power
Connection
PD5-CE10HDWRMBS PD5-
CE10HDWRMBSU
PD5-CE10HDWRMBS
PD5-
CE10HDWRMBS U
Output AC Parameters
AC-AC Eiciency 94.5% 95%
Factory-default VAC
Frequency
230 VAC, 50 Hz
Output Power
Connection
PD5-CE10HDWRMBS PD5-
CE10HDWRMBSU
PD5-CE10HDWRMBS PD5-
CE10HDWRMBS U
Waveform Sinewave
Main Mode Overload > 150% minimum 200 mS, 125 – 150% for 60 seconds; 105 – 125% for for 5 minutes; ≤ 105% continuous
Internal Battery Charger
Charger Current, A 2.25default, maximum 8 Amps

Vertiv LIEBERT GXT5 Series Specifications

General

Model	LIEBERT GXT5 Series
Product Type	UPS
Topology	Double Conversion Online
Display	LCD
Form Factor	Tower, Rackmount
Output Voltage	200/208/220/230/240 VAC
Output Frequency	50/60Hz ±0.1Hz (battery mode)
Typical Backup Time	Varies by model and load
Communication Ports	USB, RS-232
Operating Temperature	0°C to 40°C (32°F to 104°F)
Relative Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Certifications	UL, cUL, CE, RoHS
Battery Type	Valve Regulated Lead Acid (VRLA)
