Figure 10.8 Main Menu Operation and Structure
Item Description
1 Analog signals menu
2 Active alarms menu
3 History alarms menu
4 Configuration menu
5 Pressing up arrow from analog signals displays the configuration menu.
6 Pressing down arrow from configuration menu displays the analog signals menu.
NOTICE
Risk of improperly altered configuration menu settings. Can compromise equipment operation.
Changing the configuration menu settings can cause unanticipated results. These settings should be changed
only by properly trained and qualified personnel or as directed by the factory.
42 Proprietary and Confidential ©2024 Vertiv Group Corp. 10 Control Operation
Vertiv™ Liebert® MCV Installer/User Guide
