Place the crankcase front cover complete with oil pump and gas-
ket in its seat and tighten the bolts to the recommended torque.
Crankshaft oil seal front cover
Bolt (pre-treated to be re-
placed) (engine block side)
M6 (daNm) 0.8 ÷1.0
Ret the engine oil intake duct complete with O-ring in its hous-
ing and secure it by tightening the bolts to the specied torque.
Engine oil intake
VF4 Bolt M6 (daNm) 0.8 (oil pump side)
VF5 Bolt M6 (daNm) 0.9 (oil pump side)
Apply silicon sealant to the entire perimeter of the oil sump.
Place the oil sump back in its housing.
Tighten the bolts securing the oil sump to the crankcase to the
recommended torque using the tool (spanner).
Engine oil sump
Bolts front and rear M8 (daNm) 2.5
