Place a new rigid pipe between the pump and the single fuel
manifold back in its housing and tighten the connectors to the
recommended torque.
Pipes from pressure pump to fuel manifold
Connector M14 (daNm) 2.2 ÷ 2.4 (fuel manifold side)
Connector M12 (daNm) 2.2 ÷ 2.4 (pressure pump side)
Ret the auxiliary drive belt pulley and secure by tightening the
bolts to the recommended torque.
Services pulley on crankshaft
Bolt M8 (daNm) 2.3 ÷ 2.5 (crankshaft side)
Ret the timing belt guard and secure it using the bolts.
Place the exhaust manifold assembly, complete with new gasket,
back in its housing and secure it by tightening the nuts to the rec-
ommended torque.
Exhaust manifold
Nut M8 (daNm) 2.3 ÷ 2.8 (turbocharger side)
