Place the auxiliary drive belt automatic tensioner in position and
tighten the bolts to the recommended torque.
Engine components single belt moving tensioner
Bolt M8 (daNm) 2.3 ÷ 2.5
Fit and tension the single auxiliary drive belt by working on the
automatic tensioner using the tool (spanner).
Secure the electrical connection for the engine oil pressure
switch.
Secure the electrical connection for the rpm sensor
Attach the electrical connection for the coolant temperature sen-
sor.
Secure the electrical connection for the pressure relief sensor.
Secure the electrical connections for the spark plugs.
Secure the electrical connection for the pressure regulator on the
single fuel manifold.
Secure the electrical connections for the injectors.
Secure the electrical connection for the timing sensor.
Secure the electrical connection for the alternator.
Place the alternator power supply cable back in its housing and
secure it using the nut.
Secure the engine wiring using the various retaining clips.
