Fully t the toothed timing drive belt.
Use a screwdriver on the tensioner (3 a) tab for leverage until the
reference (3b) is in the maximum tension position, then lock the
nut (3c) xing the moving tensioner in this position
Remove the tools used to ad just the timing.
Rotate the crankshaft through two revolutions.
Re-check the alignment of the timing references, loosen the nut
securing the mobile tensioner and align mobile indicator (4 a) with
hole (4b), i.e. ad just to nominal tension position, then tighten nut
(4c) securing the belt tensioner to torque.
Mobile timing tensioner
Nut M8 (daNm) 2.5
Loosen the bolt retaining the timing pulley.
Rotate the crankshaft through two revolutions.
Recheck the timing by retting the timing tools
