Check the timing belt tensioner references are aligned.
Tighten the bolt xing the crankcase front cover removed previ-
ously.
Tighten the plug on the cylinder head extension for tting the ex-
haust side timing tool.
Fit the toothed timing belt protective guards and tighten the re-
taining bolts.
Position the ywheel retaining tool in its seat.
Fit the crankshaft pulley in position and tighten the xing bolts.
Flywheel lock
Bolt M8 (daNm) 2.5
Fit the xed timing belt tensioner for the single engine compo-
nent drive belt and tighten the retaining bolt to torque.
Remove the ywheel lock.
Tighten the bolt xing the exhaust side camshaft toothed pulley
to the recommended torque.
