Vicon Extra 228 - Springs and Lubrication

Preparation
23
Checking the springs
> The following must be done before the machine is connected to the
tractor:
> Pull the piston in the hydraulic cylinder out completely.
> Check that the machine is fitted with the correct springs:
If the above conditions are not met, the machine will not be able to
work satisfactorily.
Lubricating the
rotating cutterbar
> Use a grease gun and pump a suitable quantity of grease into the
holes shown.
 »Lubricants« page 94
This lubrication should be carried out the first time the Machine is put
into use.
Model Diameter of wire (mm - ’’)
228 18 (
11
/16’’)
232 18 (
11
/16’’)
Diameter of wire
