Assembly - attachment
Hydraulic connection
The tractor must be fitted with 1 set of single acting hydraulic outlets,
which are connected as follows:
> Connect the machine's hydraulic system to the tractor.
First start-up of
machine
The initial test drive of the machine is important
When the machine is connected to the tractor for the first time into
must be test driven.
Attention to the safety instructions assures your and others personal
safety.
Failure to follow the safety instructions could result in serious injuries.
> Activate the tractor's lift arms and lift the machine up.
> Activate the tractor's hydraulic system and lower the machine
down to the working position.
> Carefully connect the tractor's PTO shaft
> Carefully increase the speed on the PTO shaft to 540 RPM.
»Machine specification« page 21
> Check that the machine runs smoothly without any vibrations.
> Return the PTO shaft to idle speed.
> Disconnect the tractor shaft.
> Activate the tractor's hydraulic system and lift the machine up to
the transport position.
Hydraulic outlets on the trac-
tor
Function
Single acting
hydraulic outlet
Cutting unit
working/transport position
