Maintenance
> Locate the oilplug on the left side of the cutterbar and remove it.
• With warm oil: Wait approximately 3 minutes
• With cold oil: Wait approximately 15 minutes.
> Check the oil level using a measuring instrument and refill if
necessary.
Min. 6 mm (
1
/4”) - max 9 mm (
3
/8”)
 »Lubricants« page 94
> Fit the oilplug and tighten it fully.
